Are you looking for a strong, durable and versatile steel for your needs? Then let me introduce you to our channel steel products.
Shuangjiu Steel is a professional manufacturer and seller of channel steel, our products are made of high quality steel as the base material, which is precisely processed and treated. Channel steel is a type of steel with a unique groove structure that provides high strength, rigidity and corrosion resistance. It is used in a variety of construction, manufacturing and industrial applications.
| Produce Name | carbon steel C U channel |
| Standard | JIS, ASTM, GB, DIN, EN, AISI |
| Offer standards | ASTM A53/ASTM A573/ASTM A283 Gr.D/BS1387-1985/GB/T3091-2001,GB/T13793-92,ISO 630/E235B/JIS G3131/JIS G3106 |
| Materials | A36 |
| Q235B,Q345B | |
| S235JR/S235/S355JR/S355 | |
| SS400/SS440/SM400A/SM400B | |
| 200/300/400 series | |
| MTC report or any other requested test will be offered together with the shipping document. | |
| Length/Side length | 6m or as customer'srequest |
| Outer diameter | 6mm-2500mm (3/8"-100") |
| thickness | 1mm-150mm(SCH10-XXS) |
| Technique | Cold Drawn/Cold pilfered/Cold rolled/Hot rolled/forge-Can be processed again repeatedly |
| Other processing service | Hot dipped galvanized,pre-galvanized,color painting,coated,cuttung,bending,punching as long as u could teel us the requirments |
| Surface | Mild steel plain finish, hot dip galvanized, pre galvanized, color coated, ect. |
| Application | Foodstuff, gas, metallurgy, biology, electron, chemical, petroleum, boilers, nuclear, energy, construction field, ships building, industry, electricity industry, boiler heat exchange, machine and hardware fields and medical equipment, fertilizer, etc. |
| Inspection | Third party inspection service can be offered like ISO,SGS,BV and so on.. |
| MOQ | 1 ton |
| Lead Time | 7-14 working days after the receipt of 30% deposit |
| Payment Terms | 30%T/T Advance + 70% Balance |
| Package | Standard export waterproof package, suit for all kinds of transport, or as required. |
| JIS Standard Channels | |||
| Dimensions (mm) | Unit Weight (kg/m) | Dimensions (mm) | Unit Weight (kg/m) |
| 50X25X(3.0-5.0)X6.0 | 2.37-3.46 | 125X65X5.5X8.0 | 12.91 |
| 75X40X3.8X7.0 | 5.3 | 125X65X6.0X8.0 | 13.4 |
| 75X40X4.0X7.0 | 5.6 | 150X75X5.5X7.3 | 14.66 |
| 75X40X4.5X7.0 | 5.85 | 150X75X5.7X10.0 | 16.71 |
| 75X40X5.0X7.0 | 6.92 | 150X75X6.0X10.0 | 17.9 |
| 100X50X3.8X6.0 | 7.3 | 150X75X6.5X10.0 | 18.6 |
| 100X50X4.2X6.0 | 8.03 | 150X75X9X12.50 | 24 |
| 100X50X4.5X7.5 | 8.97 | 200X80X7.5X11.0 | 24.6 |
| 100X50X5.0X7.5 | 9.36 | 200X90X8.0X13.5 | 30.3 |
| 125X65X5.2X6.8 | 11.66 | 250X90X9.0X13.0 | 34.6 |
| 125X65X5.3X6.8 | 12.17 | 300X90X9.0X13.0 | 38.1 |
If you have any questions or need further information about ourcarbon steel C U channel, feel free to contact us at any time. We are very happy to provide you with free samples for testing and evaluation.
